Rotary Piston Volumetric Water Meter DN(15-40)

Description

Features:

● Adopting volumetric rotary piston principle of measurement,Long service life ·Dry-dial or liquid sealed register,magnetic drive,anti-magnetic interference,anti-freezing,long-term clear reading high precision,The starting flow of the meter is 2l/h orless
● Non-return valve is available.Non-return valve can keep from the back flow ·Material:Brass body orengineering plastic body,optional
● Remote transmission device can be added upon request
● Many kinds of sensors,such as Reed Switch,Hall and Weagand can be supplied upon request
● Pulse output may be 1 litter/pulse,10 litters/pulse
● It can be installed in any position
● Provided with lead seal and dustproof cover
● Confirm to IS04064;Class C or Class D;R100/R160/R200;T30 T50;- MAP16;U10D5

Working condition:

● Water temperature≤50℃
● Water pressure≤1.6 MPa(PN:1.6MPa/16bar)
● △P≤0.1MPa(Q4))
●△P≤0.063Mpa(Q3

Accuracy :

● From minimum flow-rate(Qmin)inclusive,to transitional flow-rate (Qt),exclusive:±5%
● From transitional flow-rate(Qt)inclusive,to overload flow-rate (Qs),exclusive:2%
